NFS-320 Intelligent Fire Alarm Control Panel

Send Inquiry

Request To Call Back

NFS-320 Intelligent Fire Alarm Control Panel

Name: NFS-320 Intelligent Fire Alarm Control Panel
Brand: SMVD FIRE PROTECTION
Price: 119000 INR
Availability: InStock

Price 119000 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

NFS-320 Intelligent Fire Alarm Control Panel Specification

Cabinet Material
Metal

Protection Class
Class B

Components
Main Control Board, Power Supply, Display Panel

Cover Material
Steel

Rated Operation Voltage
24V DC

Thickness
1.2 mm Cabinet Thickness

Connectivity Type
RS-232/RS-485, USB Compatible

Cooling System
Passive Cooling

Current Rating
5.25A

Protection Level
IP30

Features
Expandable, Programmable, Network Capable

Base Material
Steel

Operating Voltage
24V DC

Panel Type
Wall Mount

Control System
Microprocessor-Based

Way
One Loop (Expandable to Two Loops)

Product Type
Intelligent Fire Alarm Control Panel

Material
Metal Cabinet

Surface Finish
Powder-Coated

Standard
UL Listed

Surface Color
Red

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
5.25A

Dimension (L*W*H)
635 mm x 343 mm x 117 mm

Application
Commercial, Industrial and Institutional Buildings

IP Rating
IP30

Display Type
LCD Display

Notification Appliance Circuits (NACs)
4 onboard NACs, expandable

Expandable Loops
Supports addition of one expansion board to double loop capacity

Network Support
Compatible with NOTIFIRENET network

System Capacity
Supports up to 636 devices

Battery Backup
Supports 24V sealed lead-acid batteries

Programming
Field programmable via onboard keypad or PC

Event History Log
Up to 1000 events

Communication Protocol
FlashScan

Relative Humidity
Up to 93% non-condensing

Operating Temperature Range
0C to 49C

Alarm Devices Supported
Up to 318 (159 detectors and 159 modules) per loop

NFS-320 Intelligent Fire Alarm Control Panel Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About NFS-320 Intelligent Fire Alarm Control Panel

Select the superlative NFS-320 Intelligent Fire Alarm Control Panel for robust protection in commercial, industrial, and institutional spaces. Unlock outstanding device support with up to 318 smart devices per loop, expandable to a remarkable 636 devices. Add to Cart for an opulent security solution, boasting a microprocessor-based control system, field programmability, and comprehensive network compatibility. With a striking red, powder-coated steel cabinet and advanced FlashScan protocol, the NFS-320 ensures reliable performance, exceptional connectivity, and superior safety for diverse environments. Experience peace of mind-effortlessly.

Exceptional Application Flexibility and Designed Usage

The NFS-320 Intelligent Fire Alarm Control Panel is engineered for operational excellence across commercial, industrial, and institutional environments. Its wall-mount design and robust metal construction make it ideal for installation on masonry, steel, or finished walls. Purpose-built for system scalability, the panel excels in both new installations and upgrades, supporting secure and continuous protection. With its outstanding field programmability, users can customize settings on-site for precise and application-specific fire safety management.

Certifications, Export Process, and Main Markets

The NFS-320 Intelligent Fire Alarm Control Panel delivers confidence, certified to UL standards. Export orders are initiated upon Purchase Order confirmation, efficiently processed through FOB ports in India. Timelines from order confirmation to arrival are streamlined for swift international fulfillment. Order Completion is coordinated to meet the unique requirements of global clients, with primary export markets spanning Asia, Africa, the Middle East, and Europe. This ensures timely delivery of this trusted protection upgrade worldwide.

FAQ's of NFS-320 Intelligent Fire Alarm Control Panel:

Q: How does the NFS-320 Intelligent Fire Alarm Control Panel support expandable fire detection?

A: The NFS-320 panel supports up to 318 devices (159 detectors and 159 modules) per loop and can be expanded to double capacity with an additional board, enabling support for up to 636 devices.

Q: What specific applications is the NFS-320 designed for?

A: The NFS-320 is purpose-built for use in commercial, industrial, and institutional buildings, providing scalable protection and reliable fire detection in diverse, high-occupancy environments.

Q: What is the process to program or configure the NFS-320 panel?

A: Programming is accomplished either through the onboard keypad or by connecting a PC. This allows for field customization and swift adjustments as needed.

Q: When does order completion and port dispatch typically occur for international clients?

A: Order completion and port dispatch are initiated upon confirmation of the purchase order, ensuring prompt handling and timely shipment to the designated FOB port.

Q: Where is the panel typically installed, and what is its protection level?

A: The panel is designed for wall mounting inside buildings, with an IP30 rated metal cabinet to provide reliable environmental protection and security.

Q: What are the benefits of the NFS-320's network compatibility?

A: Its compatibility with the NOTIFIRENET network allows for system integration, remote monitoring, and centralized management across multiple sites, enhancing operational efficiency and response.
